深圳德冠精密是专业开发、设计、生产、销售D-SUB系列连接器的生产厂家,拥有上千种型号的D-SUB连接器,品质保证,交货快捷,免费试样拨打热线：0755-2950-2489

德冠连接器产品说明：

Terminal material: C5191/C2680

Skin texture: SUS/SPCC/SPCD

Plastic material: PA9T/PBT/PBC/PA6T

Terminal plating: gold-plated 1u

Case plating: black nickel plating/weldability nickel plating

Packing: packing with packing/blister box

Plastic color: blue/black/white/yellow

Rated current: 0.5a, rated voltage: 50v dc

Operating temperature: available at -25 to 85 degrees

终端应用：手机usb数据线、电脑usb接口、各类电子产品usb充电器、移动电源、hdmi电视接口等家用电器和电子产品。

德冠连接器产品：

Electrical properties:

Contact impedance: tested at 1khz and small current, the maximum impedance is 40 microohms

Insulation resistance: test with 100-250v dc voltage, lasting 1 minute, minimum impedance 100 megohm

Voltage resistance: add ac 250v between terminals and terminals, no breakdown phenomenon

Mechanical properties:

Insert force and pull out force: insert and pull out the fixture at a speed of 25 mm per minute

Terminal strength: pull out the terminals horizontally, and the single pin maintains a minimum of 10n

Durability test: maximum terminal contact resistance of 100 milliohms, 10 times/min plug speed, up to 5000 times

德冠产品运用中端：

电脑、手机数据线、电视、机顶盒、移动电源等覆盖电子产品及家用电器产品制造商。

德冠现有客户：

产品终端：联想、华为、步步高，伟创等；

直接客户：航嘉、声亿、华友达、太康、立群等；

德冠主要产品有D-SUB系列，USB系列，HDMI.DVI系列,RJ45系列,卡座系列，DP系列，SLOT系列，JACK系列和其他系列连接器，适用于各种电子产品，型号多，交货快，价格实惠，免费取样，欢迎来电洽谈！
